Power seats circuit for Audi SQ5 Sportback FY (2020-2024)

Power seats circuit (1 of 2)

SQ5 Sportback Audi FY (2020-2024): Power seats circuit (1 of 2)

Get access

BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER BACKREST ADJUSTMENT MOTOR DRIVER BACKREST ADJUSTMENT SWITCH DRIVER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 DRIVER SEAT ADJUSTMENT CONTROL HEAD DRIVER SEAT ANGLE ADJUSTMENT MOTOR DRIVER SEAT ANGLE ADJUSTMENT SWITCH DRIVER SEAT BACKREST COUPLING POINT DRIVER SEAT FORWARD/BACK ADJUSTMENT MOTOR DRIVER SEAT FORWARD/BACK ADJUSTMENT SWITCH DRIVER SEAT HEIGHT ADJUSTMENT MOTOR DRIVER SEAT HEIGHT ADJUSTMENT SWITCH GRN/BRN WIRE GRN/RED WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES LEFT FRONT SEAT COUPLING STATION RED WIRE RED/BLK WIRE RELAY & FUSE PANEL 1 VIO WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE

Power seats circuit (2 of 2)

SQ5 Sportback Audi FY (2020-2024): Power seats circuit (2 of 2)

Get access

BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FRONT PASSENGER BACKREST ADJUSTMENT MOTOR FRONT PASSENGER BACKREST ADJUSTMENT SWITCH FRONT PASSENGER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 FRONT PASSENGER SEAT ADJUSTMENT CONTROL HEAD FRONT PASSENGER SEAT ANGLE ADJUSTMENT BUTTON FRONT PASSENGER SEAT ANGLE ADJUSTMENT MOTOR FRONT PASSENGER SEAT BACKREST COUPLING POINT FRONT PASSENGER SEAT FORWARD/BACK ADJUSTMENT MOTOR FRONT PASSENGER SEAT FORWARD/BACK ADJUSTMENT SWITCH FRONT PASSENGER SEAT HEIGHT ADJUSTMENT MOTOR FRONT PASSENGER SEAT HEIGHT ADJUSTMENT SWITCH GRN/BRN WIRE GRN/RED WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES RED WIRE RED/BLK WIRE RELAY & FUSE PANEL 2 RIGHT FRONT SEAT COUPLING STATION VIO WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE
