Electromechanical power steering circuit for Audi SQ5 Sportback FY (2020-2024)
Electromechanical power steering circuit
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DISPLAY UNIT
ELECTROMECHANICAL POWER STEERING INDICATOR LAMP
ELECTROMECHANICAL POWER STEERING MOTOR
FUSE 1
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
MAIN FUSE CARRIER (TOP OF BATTERY)
NCA WIRE
ORG/BRN WIRE
ORG/VIO WIRE
PNK WIRE
POWER STEERING CONTROL MODULE
RED WIRE
RIGHT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
STEERING ANGLE SENSOR
STEERING COLUMN ELECTRONICS CONTROL MODULE
STEERING TORQUE SENSOR
SUPPLEMENTAL RESTRAINTS SYSTEM
