Active steering control module circuit for Audi SQ5 Sportback FY (2020-2024)
Active steering control module circuit
ACTIVE STEERING CONTROL MODULE
ACTIVE STEERING MOTOR
ACTIVE STEERING MOTOR ROTOR POSITION SENSOR
ACTIVE STEERING SAFETY LOCK ACTUATOR
BLK WIRE
BLU WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
FUSE 10
FUSE PANEL 5
FUSE PANEL B
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
NCA WIRE
PNK WIRE
PNK/WHT WIRE
RED WIRE
RELAY & FUSE PANEL 1
SUPPLEMENTAL RESTRAINTS SYSTEM
WHT WIRE
YEL WIRE
YEL/BRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
YEL/WHT WIRE
