Rear defogger & heated mirrors circuit for Audi SQ5 Sportback FY (2020-2024)
Rear defogger & heated mirrors circuit
BLK WIRE
BLK/BLU WIRE
BRN WIRE
BRN/WHT WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE
DRIVER EXTERIOR REAR VIEW MIRROR
FRONT A/C DISPLAY CONTROL HEAD
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER EXTERIOR REAR VIEW MIRROR
FUSE 11
FUSE 14
FUSE 5
FUSE 7
FUSE PANEL 1
FUSE PANEL 2
FUSE PANEL 3
FUSE PANEL B
FUSE PANEL F
GRN/VIO WIRE
HEATER
HOT AT ALL TIMES
INTERMEDIATE CIRCUIT CAPACITOR 1
LEFT FRONT DOOR COUPLING POINT
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER RELAY
REAR WINDOW DEFOGGER SUPPRESSOR
REAR WINDOW DEFOGGER SUPPRESSOR 2
RED/VIO WIRE
RED/WHT WIRE
RELAY & FUSE PANEL 1
RELAY & FUSE PANEL 2
RIGHT FRONT DOOR COUPLING POINT
WHT/YEL WIRE
