Headlights circuit, w/o hid w/o metrix beam for Audi S8 D4 facelift (2013-2018)

BLK/GRN WIRE BLK/RED WIRE BLU/RED WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CRUISE CONTROL/ TURN SIGNAL/ HEADLAMP FLASHER SWITCH FOG LAMP BUTTON FOG LAMP INDICATOR LAMP FUSE 1 FUSE 12 FUSE 8 FUSE 9 FUSE CARRIER 2 FUSE CARRIER 3 FUSE PANEL C GRN/BLK WIRE GRN/RED WIRE GRY/BLK WIRE HEADLAMP SWITCH ILLUMINATION BULB HOT AT ALL TIMES INSTRUMENT PANEL ILLUMINATION DIMMER SWITCH LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE, LEFT FRONT TURN SIGNAL BULB LEFT FRONT SIDE MARKER LAMP BULB LEFT HEADLAMP ASSEMBLY LEFT HEADLAMP CURRENT CODING RESISTANCE 1 LEFT HEADLAMP FAN LEFT HEADLAMP TEMPERATURE SENSOR 1 LEFT HEADLAMP TEMPERATURE SENSOR 2 LEFT HEADLAMP TEMPERATURE SENSOR 3, LEFT HEADLAMP CURRENT CODING RESISTANCE 2 LEFT HIGH BEAM HEADLAMP BULB LEFT LED HEADLAMP POWER OUTPUT MODULE 1 LEFT LED HEADLAMP POWER OUTPUT MODULE 2 LEFT LOW BEAM HEADLAMP BULB LEFT STATIONARY CORNERING LAMP LIGHT SWITCH NCA WIRE NIGHT VISION SYSTEM BUTTON ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE POSITION LAMP INDICATOR LAMP POWER DISTRIBUTION SYSTEM RAIN/LIGHT RECOGNITION SENSOR REAR FOG LAMP BUTTON REAR FOG LAMP INDICATOR LAMP RED/BLK WIRE RED/VIO WIRE RED/WHT WIRE STEERING COLUMN ELECTRONICS CONTROL MODULE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/BLK WIRE VIO/BRN WIRE WHT/BLK WIRE WHT/RED WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU/RED WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CORNERING LAMP, HEADLAMP RANGE CONTROL MODULE DISPLAY UNIT ELECTRO- MECHANICAL PARKING BRAKE BUTTON ELECTRO- MECHANICAL PARKING BRAKE CONTROL MODULE FUSE 1 FUSE 16 FUSE 6 FUSE CARRIER 1 FUSE CARRIER 2 FUSE PANEL F GRN/RED WIRE GRN/VIO WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE GRY/YEL WIRE HIGH BEAM INDICATOR LAMP HOT W/ TERMINAL 15 POWER SUPPLY RELAY 2 ENERGIZED INSTRUMENT CLUSTER CONTROL MODULE ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/VIO WIRE POWER DISTRIBUTION SYSTEM RIGHT FRONT SIDE MARKER LAMP BULB RIGHT HEADLAMP ASSEMBLY RIGHT HEADLAMP CURRENT CODING RESISTANCE 1 RIGHT HEADLAMP FAN RIGHT HEADLAMP TEMPERATURE SENSOR 1 RIGHT HEADLAMP TEMPERATURE SENSOR 2 RIGHT HEADLAMP TEMPERATURE SENSOR 3, RIGHT HEADLAMP CURRENT CODING RESISTANCE 2 RIGHT HIGH BEAM HEADLAMP BULB RIGHT LED HEADLAMP POWER OUTPUT MODULE 1 RIGHT LED HEADLAMP POWER OUTPUT MODULE 2 RIGHT LOW BEAM HEADLAMP BULB RIGHT STATIONARY CORNERING LAMP WHT/RED WIRE YEL/RED WIRE
