Audi S8 D4 facelift (2013-2018) auxiliary heater temperature sensor 2 Wiring diagram
This page shows the only wiring diagram for the component.auxiliary heater temperature sensor 2, which is found in the car Audi S8 D4 facelift (2013-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auxiliary heater temperature sensor 2 (1 of 1)
3.0L TURBO DIESEL
AUXILIARY HEATER ANTENNA
AUXILIARY HEATER CONTROL MODULE (UNDER RIGHT HEADLIGHT)
AUXILIARY HEATER FUSE
AUXILIARY HEATER RADIO RECEIVER
AUXILIARY HEATER TEMPERATURE SENSOR 2
BLK WIRE
BLK/RED WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
COMBUSTION AIR BLOWER
COMPUTER DATA LINES SYSTEM
FLAME MONITOR
FUEL PREHEATING ELEMENT
FUSE
FUSE 13
FUSE 5
FUSE CARRIER 2
FUSE PANEL B
FUSE PANEL C
GRN WIRE
HEATER COOLANT SHUT-OFF VALVE
HEATER GLOW PLUG
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
METERING PUMP
NCA WIRE
ORG/BLU WIRE
ORG/BRN WIRE
RECIRCULATION PUMP
RED WIRE
RED/GRN WIRE
RIGHT END OF DASH)
ROOF ANTENNA
TEMPERATURE SENSOR
VIO WIRE
WHT WIRE
WHT/GRN WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component -> Auxiliary heater circuit -> AUXILIARY HEATER TEMPERATURE SENSOR 2
