Audi S8 D3 facelift (2007-2011) front passenger's door contact switch wiring diagram
This page shows the only wiring diagram for the component.front passenger's door contact switch, which is found in the car Audi S8 D3 facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
front passenger's door contact switch wiring diagram (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU/YEL WIRE
BRN WIRE
DEFOGGER SYSTEM
FRONT PASSENGER'S CENTRAL LOCKING SAFE INDICATOR LAMP
FRONT PASSENGER'S DOOR AMBIENT ILLUMINATION
FRONT PASSENGER'S DOOR CONTACT SWITCH
FRONT PASSENGER'S DOOR OPENER ILLUMINATION
FRONT PASSENGER'S DOOR STORAGE ILLUMINATION
FRONT PASSENGER'S DOOR WARNING LIGHT
FRONT PASSENGER'S ENTRY LAMP (IN OUTSIDE MIRROR)
FRONT PASSENGER'S INTERIOR LOCK SWITCH
FUSE 39
GRN WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
NCA WIRE
PASSENGER DOOR WINDOW REGULATOR SWITCH
RED/BLU WIRE
RED/WHT WIRE
RIGHT FRONT ENTRY LIGHT
RIGHT FRONT OUTSIDE DOOR HANDLE ILLUMINATION
RIGHT INSTRUMENT PANEL FUSE HOLDER (IN RIGHT END OF DASH)
Go to component -> Interior lights circuit (5 of 7) -> FRONT PASSENGER'S DOOR CONTACT SWITCH
