Audi S8 D3 facelift (2007-2011) antenna amplifier, antenna amplifier shield wiring diagram
This page shows the only wiring diagram for the component.antenna amplifier, antenna amplifier shield, which is found in the car Audi S8 D3 facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
antenna amplifier, antenna amplifier shield wiring diagram (1 of 1)
ANTENNA AMPLIFIER, ANTENNA AMPLIFIER SHIELD
BLK WIRE
BRN WIRE
BRN/WHT WIRE
DATA BUS BOARD DIAGNOSTIC INTERFACE
FRESH AIR BLOWER CONTROL MODULE, COOLANT FAN COOLANT FAN 2
HEATED REAR WINDOW
IGNITION COILS 1, 2, 3, 4 (4.2L)
IGNITION COILS 5, 6, 7, 8 (4.2L)
MICROPHONE UNIT SHIELD
NAVIGATION (GPS) ANTENNA SHIELD, ANTENNA AMPLIFIER, ANTENNA AMPLIFIER SHIELD
PASSENGER MEMORY SEAT CONTROL MODULE
PASSENGER'S SEAT BACKREST BOLSTER HEATER, PASSENGER'S BACKREST HEATING ELEMENT
PASSENGER'S SEAT SIDE BOLSTER HEATER, PASSENGER'S SEAT HEATING ELEMENT
ROOF ELECTRONICS CONTROL MODULE
SUPPRESSOR, TRANSMISSION CONTROL MODULE
Go to component -> Ground distribution circuit (2 of 3) -> ANTENNA AMPLIFIER, ANTENNA AMPLIFIER SHIELD
