Front heated seats circuit, w/o ventilation w/ standard & comfort seats for Audi S7 4K (2019-2024)
Front heated seats circuit, w/o ventilation w/ standard & comfort seats
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER BACKREST HEATING ELEMENT
DRIVER SEAT COUPLING POINT
DRIVER SEAT HEATING ELEMENT
FRONT INFORMATION DISPLAY CONTROL HEAD
FRONT PASSENGER BACKREST HEATING ELEMENT
FRONT PASSENGER SEAT COUPLING POINT
FRONT PASSENGER SEAT HEATING ELEMENT
FUSE 10
FUSE PANEL D (LEFT KICK PANEL)
GRN WIRE
HOT AT ALL TIMES
LEFT FRONT SEAT COUPLING STATION
LEFT FRONT SEAT TEMPERATURE SENSOR
LEFT SEAT HEATING BUTTON
OCCUPANT DETECTION SYSTEM CONTROL MODULE
ORG/BRN WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT FRONT SEAT COUPLING STATION
RIGHT FRONT SEAT TEMPERATURE SENSOR
RIGHT SEAT HEATING BUTTON
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
WHT WIRE
WHT/VIO WIRE
WHT/YEL WIRE
