Headlights circuit, w/ multiple matrix beam for Audi S7 4K (2019-2024)

AUTOMATIC HIGH BEAM ASSIST CONTROL MODULE BLU WIRE BRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM COUPLING POINT ON ROOF ELECTRO- MECHANICAL PARKING BRAKE BUTTON FOG LAMP BUTTON FOG LAMP INDICATOR LAMP FUSE 12 FUSE 3 FUSE 5 FUSE 9 FUSE PANEL B FUSE PANEL D FUSE PANEL F FUSE PANEL H GRN WIRE GRN/VIO WIRE GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE GRY/YEL WIRE HEADLAMP SWITCH ILLUMINATION BULB HOT AT ALL TIMES HUMIDITY SENSOR INSTRUMENT CLUSTER CONTROL MODULE INTERIOR REAR VIEW MIRROR LEFT FRONT LEVEL CONTROL SYSTEM SENSOR LEFT REAR LEVEL CONTROL SYSTEM SENSOR LIGHT RECOGNITION SENSOR LIGHT SWITCH ORG/BRN WIRE PARKING BRAKE BUTTON POSITION LAMP INDICATOR LAMP POWER DISTRIBUTION SYSTEM RAIN/LIGHT RECOGNITION SENSOR REAR FOG LAMP BUTTON REAR FOG LAMP INDICATOR LAMP RED WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/WHT WIRE W/ MULTI-FUNCTION CAMERA W/O MULTI-FUNCTION CAMERA WHT/GRN WIRE WHT/RED WIRE YEL/BRN WIRE YEL/GRY WIRE

BRN WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE GRY/YEL WIRE LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE LEFT FRONT HEADLAMP LEFT FRONT SIDE MARKER LAMP BULB LEFT FRONT TURN SIGNAL BULB LEFT HEADLAMP 16-PIN CONNECTOR LEFT HEADLAMP 8-PIN CONNECTOR LEFT HEADLAMP FAN LEFT HEADLAMP RANGE CONTROL ADJUSTMENT MOTOR LEFT HEADLAMP TEMPERATURE SENSOR 2 LEFT HEADLAMP TEMPERATURE SENSOR 3 LEFT HEADLAMP TEMPERATURE SENSOR 4 LEFT HEADLAMP TEMPERATURE SENSOR 5 LEFT HEADLAMP TEMPERATURE SENSOR 6 LEFT HIGH BEAM HEADLAMP BULB LEFT LED HEADLAMP POWER OUTPUT MODULE 1 LEFT LED HEADLAMP POWER OUTPUT MODULE 2 LEFT LOW BEAM HEADLAMP BULB LEFT MATRIX HEADLAMP POWER OUTPUT MODULE LEFT STATIONARY CORNERING LAMP ORG/BRN WIRE PNK WIRE WHT/GRN WIRE WHT/RED WIRE

BRN WIRE COMPUTER DATA LINES SYSTEM GRY WIRE ORG/BRN WIRE RIGHT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE RIGHT FRONT HEADLAMP RIGHT FRONT SIDE MARKER LAMP BULB RIGHT FRONT TURN SIGNAL BULB RIGHT HEADLAMP 16-PIN CONNECTOR RIGHT HEADLAMP 8-PIN CONNECTOR RIGHT HEADLAMP FAN RIGHT HEADLAMP RANGE CONTROL ADJUSTMENT MOTOR RIGHT HEADLAMP TEMPERATURE SENSOR 2 RIGHT HEADLAMP TEMPERATURE SENSOR 3 RIGHT HEADLAMP TEMPERATURE SENSOR 4 RIGHT HEADLAMP TEMPERATURE SENSOR 5 RIGHT HEADLAMP TEMPERATURE SENSOR 6 RIGHT HIGH BEAM HEADLAMP BULB RIGHT LED HEADLAMP POWER OUTPUT MODULE 1 RIGHT LED HEADLAMP POWER OUTPUT MODULE 2 RIGHT LOW BEAM HEADLAMP BULB RIGHT MATRIX HEADLAMP POWER OUTPUT MODULE RIGHT STATIONARY CORNERING LAMP WHT/RED WIRE
