Wiring diagram engine performance 2.9l turbo, structure borne sound actuator circuit for Audi S7 4K (2019-2024)

Wiring diagram engine performance 2.9l turbo, structure borne sound actuator circuit

S7 Audi 4K (2019-2024): Wiring diagram engine performance 2.9l turbo, structure borne sound actuator circuit

Get access

BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 3 FUSE PANEL E GRY WIRE GRY/BRN WIRE GRY/RED WIRE HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED IN PLENUM CHAMBER) ORG/BRN WIRE RED/BLK WIRE STRUCTURE BORNE SOUND ACTUATOR STRUCTURE BORNE SOUND CONTROL MODULE
