Audi S7 4K (2019-2024) steering column axial adjustment sensor Wiring diagrams
This page contains all the electrical diagrams for the component. steering column axial adjustment sensor, in which he is found in the car Audi S7 4K (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram steering column axial adjustment sensor (1 of 2)
BRN WIRE
FUSE 2
FUSE PANEL F
GRY/BLU WIRE
HOT AT ALL TIMES
POWER ADJUSTABLE STEERING COLUMN CONTROL MODULE
RED/BLU WIRE
STEERING COLUMN ADJUSTMENT SWITCH
STEERING COLUMN AXIAL ADJUSTMENT SENSOR
STEERING COLUMN FORWARD/BACK ADJUSTMENT MOTOR
STEERING COLUMN VERTICAL ADJUSTMENT MOTOR
STEERING COLUMN VERTICAL ADJUSTMENT SENSOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/BLU WIRE
YEL/BLK WIRE
Go to component -> Power tilt steering column circuit -> STEERING COLUMN AXIAL ADJUSTMENT SENSOR
Wiring diagram steering column axial adjustment sensor (2 of 2)
BLU/BRN WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE
DRIVER SEAT MEMORY BUTTON
DRIVER SEAT MEMORY SETTINGS CONTROL HEAD
DRIVER SIDE INDICATOR LAMP FOR MEMORY SEAT
FUSE 2
FUSE 5
FUSE PANEL D
FUSE PANEL F
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR COUPLING POINT
MEMORY SEAT POSITION 1 BUTTON
MEMORY SEAT POSITION 2 BUTTON
ORG/BRN WIRE
POWER ADJUSTABLE STEERING COLUMN CONTROL MODULE
RED/BLU WIRE
RED/VIO WIRE
STEERING COLUMN ADJUSTMENT SWITCH
STEERING COLUMN AXIAL ADJUSTMENT SENSOR
STEERING COLUMN FORWARD/BACK ADJUSTMENT MOTOR
STEERING COLUMN VERTICAL ADJUSTMENT MOTOR
STEERING COLUMN VERTICAL ADJUSTMENT SENSOR
VIO/BLU WIRE
YEL/BLK WIRE
Go to component -> Steering column memory circuit -> STEERING COLUMN AXIAL ADJUSTMENT SENSOR
