Audi S7 4K (2019-2024) selector lever position sensor Wiring diagrams
This page contains all the electrical diagrams for the component. selector lever position sensor, in which he is found in the car Audi S7 4K (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram selector lever position sensor (1 of 3)
4-PIN CONNECTOR IN THE STEERING WHEEL
BLU WIRE
BRN WIRE
BUTTON
COMPUTER DATA LINES SYSTEM
D/S
FUSE 9
FUSE PANEL M
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INDICATOR
LAMP
LEFT MULTI-FUNCTION BUTTONS ON STEERING WHEEL
LOCK
MULTI-FUNCTION STEERING WHEEL CONTROL MODULE
NCA WIRE
ORG/BRN WIRE
PARKING
PNK WIRE
RED WIRE
RED/GRN WIRE
RED/VIO WIRE
RIGHT MULTI-FUNCTION STEERING WHEEL BUTTON
SEATS SYSTEM
SELECTOR LEVER
SELECTOR LEVER POSITION SENSOR
SELECTOR LEVER RELEASE BUTTON
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
SELECTOR LEVER TRANSMISSION RANGE DISPLAY
SHIFT LOCK SOLENOID
SPIRAL SPRING
STEERING COLUMN ELECTRONICS CONTROL MODULE
STEERING WHEEL HEATING BUTTON
TIPTRONIC DOWNSHIFT BUTTON
TIPTRONIC UPSHIFT BUTTON
TRANSVERSE SELECTOR LEVER LOCK MOTOR
TRANSVERSE SELECTOR LEVER LOCK SENSOR
VIO WIRE
Go to component -> A/t circuit (2 of 2) -> SELECTOR LEVER POSITION SENSOR
Wiring diagram selector lever position sensor (2 of 3)
BLU WIRE
BRN WIRE
CENTER TAIL LAMP
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
FUSE 9
FUSE PANEL H
GRN WIRE
GRN/BLK WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
LEFT BACKUP LAMP BULB
NCA WIRE
ORG/BRN WIRE
RED/YEL WIRE
RIGHT BACKUP LAMP BULB
SELECTOR LEVER
SELECTOR LEVER POSITION SENSOR
SELECTOR LEVER TRANSMISSION RANGE DISPLAY
Go to component -> Backup lamps circuit -> SELECTOR LEVER POSITION SENSOR
Wiring diagram selector lever position sensor (3 of 3)
ABS CONTROL MODULE
BLK WIRE
BLU WIRE
BRAKE LAMP SWITCH
BRAKE PEDAL POSITION SENSOR
BRAKE PEDAL SWITCH
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
D/S
ENGINE/MOTOR CONTROL MODULE
FUSE 5
FUSE 9
FUSE PANEL A
FUSE PANEL M
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED
IN PLENUM CHAMBER)
INSTRUMENT CLUSTER CONTROL MODULE
NCA WIRE
ORG/BRN WIRE
PARKING LOCK BUTTON
PARKING LOCK BUTTON/INDICATOR LAMP, SELECTOR LEVER RELEASE BUTTON
PARKING LOCK INDICATOR LAMP
PNK WIRE
PNK/WHT WIRE
RED/VIO WIRE
SELECTOR LEVER
SELECTOR LEVER POSITION SENSOR
SELECTOR LEVER RELEASE BUTTON
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
SELECTOR LEVER TRANSMISSION RANGE DISPLAY
SHIFT LOCK SOLENOID
SYSTEM
TRANSMISSION CONTROL MODULE
TRANSVERSE SELECTOR LEVER LOCK MOTOR
TRANSVERSE SELECTOR LEVER LOCK SENSOR
VIO/RED WIRE
Go to component -> Shift interlock circuit -> SELECTOR LEVER POSITION SENSOR
