Audi S7 4K (2019-2024) rear spoiler adjustment indicator lamp Wiring diagram
This page shows the only wiring diagram for the component.rear spoiler adjustment indicator lamp, which is found in the car Audi S7 4K (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear spoiler adjustment indicator lamp (1 of 1)
BLU WIRE
BLU/GRN WIRE
BRN WIRE
BRN/GRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
FRONT INFORMATION DISPLAY CONTROL HEAD 2
FUSE 7
FUSE 8
FUSE PANEL F
FUSE PANEL H
GRN/BLU WIRE
HOT AT ALL TIMES
ORG/BRN WIRE
REAR SPOILER ADJUSTMENT DRIVE UNIT
REAR SPOILER ADJUSTMENT INDICATOR LAMP
REAR SPOILER ADJUSTMENT SWITCH
REAR SPOILER CONTROL MODULE
REAR SPOILER MOTOR
REAR SPOILER STOP SWITCH 1
REAR SPOILER STOP SWITCH 2
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
VIO/GRY WIRE
WHT WIRE
WHT/BLU WIRE
YEL/BLU WIRE
Go to component -> Active bodyworks circuit -> REAR SPOILER ADJUSTMENT INDICATOR LAMP
