Audi S7 4K (2019-2024) passenger side interior door handle illumination lamp Wiring diagram
This page shows the only wiring diagram for the component.passenger side interior door handle illumination lamp, which is found in the car Audi S7 4K (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger side interior door handle illumination lamp (1 of 1)
BLU/GRY WIRE
BLU/VIO WIRE
BRN WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/YEL WIRE
COMPUTER
COMPUTER DATA LINES SYSTEM
COUPLING POINT IN THE RIGHT FRONT DOOR
DATA LINES
DRIVER DOOR CONTACT SWITCH
DRIVER DOOR LOCK UNIT
FRONT PASSENGER DOOR CONTACT SWITCH
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER DOOR LOCK UNIT
FRONT PASSENGER EXIT WARNING LAMP
FRONT PASSENGER EXTERIOR DOOR HANDLE ILLUMINATION LAMP
FRONT PASSENGER SIDE DOOR CONTOUR ILLUMINATION LAMP
FRONT PASSENGER SIDE SILL PANEL STRIP AMBIENT LIGHTING LAMP
FUSE 14
FUSE PANEL B
GRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
ORG/BRN WIRE
PASSENGER SIDE DOOR AMBIENT LIGHTING LAMP
PASSENGER SIDE ENTRY LAMP
PASSENGER SIDE INTERIOR DOOR HANDLE ILLUMINATION LAMP
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RIGHT DOOR STORAGE COMPARTMENT ILLUMINATION LAMP
RIGHT FRONT DOOR COUPLING POINT
SYSTEM
VIO WIRE
VIO/YEL WIRE
W/ AMBIENT LIGHTING
W/ AUXILIARY LAMPS
WHT WIRE
Go to component -> Courtesy lamps circuit (4 of 6) -> PASSENGER SIDE INTERIOR DOOR HANDLE ILLUMINATION LAMP
