Audi S7 4K (2019-2024) left instrument panel vent illumination bulb left side vent position sensor Wiring diagram
This page shows the only wiring diagram for the component.left instrument panel vent illumination bulb left side vent position sensor, which is found in the car Audi S7 4K (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left instrument panel vent illumination bulb left side vent position sensor (1 of 1)
ACCESS/START AUTHORIZATION BUTTON
AIR CONDITION SYSTEM PLUS
BRN WIRE
BULB
BUTTON
CENTER COUPLING POINT ON INSTRUMENT PANEL
CENTER INSTRUMENT PANEL VENT ILLUMINATION BULB RIGHT CENTER VENT POSITION SENSOR
COMPUTER DATA LINES SYSTEM
DVD PLAYER
FOG LAMP
FUSE 10
FUSE 5
FUSE PANEL D
FUSE PANEL F
GLOVE COMPARTMENT WIRING HARNESS COUPLING POINT
GRN WIRE
GRN/GRY WIRE
GRN/YEL WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HEADLAMP
HOT AT ALL TIMES
ILLUMINATION
INDICATOR
LAMP
LEFT INSTRUMENT PANEL VENT ILLUMINATION BULB LEFT CENTER VENT POSITION SENSOR
LEFT INSTRUMENT PANEL VENT ILLUMINATION BULB LEFT SIDE VENT POSITION SENSOR
LIGHT SWITCH
ORG/BRN WIRE
POSITION
REAR FOG
RED/GRY WIRE
RIGHT INSTRUMENT PANEL VENT ILLUMINATION BULB RIGHT SIDE VENT POSITION SENSOR
SWITCH
USB CONNECTION 1
USB DISTRIBUTOR
VALET PARKING LOCK BUTTON
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/WHT WIRE
W/ REAR CLIMATRONICS, IMPACT PRESSURE SENSOR
Go to component -> Instrument illumination circuit (1 of 3) -> LEFT INSTRUMENT PANEL VENT ILLUMINATION BULB LEFT SIDE VENT POSITION SENSOR
