Audi S7 4K (2019-2024) left headlamp current coding resistance 1 Wiring diagram
This page shows the only wiring diagram for the component.left headlamp current coding resistance 1, which is found in the car Audi S7 4K (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left headlamp current coding resistance 1 (1 of 1)
AUTOMATIC HIGH BEAM ASSIST CONTROL MODULE
BRN WIRE
COMPUTER DATA LINES SYSTEM
GRY WIRE
INTERIOR REAR VIEW MIRROR
LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE
LEFT FRONT HEADLAMP
LEFT FRONT TURN SIGNAL BULB
LEFT HEADLAMP 3-PIN CONNECTOR
LEFT HEADLAMP 7-PIN CONNECTOR
LEFT HEADLAMP BEAM ADJUSTMENT MOTOR
LEFT HEADLAMP CURRENT CODING RESISTANCE 1
LEFT HEADLAMP TEMPERATURE SENSOR 1
LEFT HEADLAMP TEMPERATURE SENSOR 2
LEFT HEADLAMP TEMPERATURE SENSOR 3
LEFT HIGH BEAM HEADLAMP BULB
LEFT LED HEADLAMP POWER OUTPUT MODULE 1
LEFT LED HEADLAMP POWER OUTPUT MODULE 2
LEFT LOW BEAM HEADLAMP BULB
LEFT STATIONARY CORNERING LAMP
LIGHT RECOGNITION SENSOR
ORG/BRN WIRE
WHT/GRN WIRE
WHT/RED WIRE
Go to component -> Headlights circuit, w/o multiple matrix beam & additional laser high beam (2 of 3) -> LEFT HEADLAMP CURRENT CODING RESISTANCE 1
