Audi S7 4K (2019-2024) epc throttle drive angle sensor 2 Wiring diagram
This page shows the only wiring diagram for the component.epc throttle drive angle sensor 2, which is found in the car Audi S7 4K (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram epc throttle drive angle sensor 2 (1 of 1)
7 SPEED TRANSMISSION
8 SPEED TRANSMISSION
AUTOMATIC TRANSMISSION COUPLING POINT
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL IND LAMP
ENGINE SPEED SENSOR
ENGINE/MOTOR CONTROL MODULE
EPC THROTTLE DRIVE
EPC THROTTLE DRIVE ANGLE SENSOR 1
EPC THROTTLE DRIVE ANGLE SENSOR 2
FUSE 14
FUSE 8
FUSE 9
FUSE PANEL A
FUSE PANEL E
GRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRY/YEL WIRE
HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
INSTRUMENT CLUSTER CONTROL MODULE
ORG/BRN WIRE
PNK WIRE
RED/YEL WIRE
THROTTLE VALVE CONTROL MODULE (ON THROTTLE BODY ASSEMBLY)
WHT/RED WIRE
YEL/BLU WIRE
Go to component -> Cruise control circuit (1 of 2) -> EPC THROTTLE DRIVE ANGLE SENSOR 2
