Audi S7 4K (2019-2024) driver side second row seat belt switch Wiring diagram
This page shows the only wiring diagram for the component.driver side second row seat belt switch, which is found in the car Audi S7 4K (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side second row seat belt switch (1 of 1)
BLK/GRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
CENTER REAR SEAT BELT LATCH LAMP
CENTER SECOND ROW SEAT BELT SWITCH
COMPUTER DATA LINES SYSTEM
DRIVER SIDE SECOND ROW SEAT BELT SWITCH
FRONT PASSENGER AIR BAG DISABLED INDICATOR LAMP
FRONT PASSENGER SEAT BELT SWITCH
FRONT PASSENGER SEAT BELT TENSIONER IGNITER 2
FRONT PASSENGER SEAT HEATING ELEMENT
FRONT PASSENGER SEAT POSITION SENSOR
FRONT ROOF MODULE
GRN WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY/YEL WIRE
PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE
PASSENGER SEAT OCCUPANT DETECTION SENSOR
PASSENGER SIDE REAR SEAT BELT LATCH LAMP
PASSENGER SIDE SECOND ROW SEAT BELT SWITCH
REAR DRIVER SIDE SEAT BELT LATCH LAMP
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RIGHT FRONT SEAT COUPLING STATION
SEATS SYSTEM
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
VIO/BLU WIRE
VIO/RED WIRE
WHT WIRE
WHT/YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit (2 of 5) -> DRIVER SIDE SECOND ROW SEAT BELT SWITCH
