Audi S7 4K (2019-2024) driver front air bag crash sensor Wiring diagram
This page shows the only wiring diagram for the component.driver front air bag crash sensor, which is found in the car Audi S7 4K (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver front air bag crash sensor (1 of 1)
AIR BAG CONTROL MODULE
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/GRN WIRE
BRN WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER FRONT AIR BAG CRASH SENSOR
DRIVER SEAT BELT TENSIONER IGNITER 2
DRIVER SIDE REAR THORAX AIR BAG CRASH SENSOR
DRIVER THORAX AIR BAG CRASH SENSOR
DRIVER'S DOOR
FRONT PASSENGER THORAX AIR BAG CRASH SENSOR
GRN WIRE
GRN/WHT WIRE
GRY WIRE
LEFT FRONT BUMPER COUPLING POINT
LEFT FRONT DOOR COUPLING POINT
ORG/BRN WIRE
PASSENGER SIDE FRONT AIR BAG CRASH SENSOR
PASSENGER SIDE REAR THORAX AIR BAG CRASH SENSOR
PNK WIRE
PNK/WHT WIRE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RIGHT FRONT BUMPER COUPLING POINT
RIGHT FRONT DOOR COUPLING POINT
VIO WIRE
VIO/BLU WIRE
WHT WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit (3 of 5) -> DRIVER FRONT AIR BAG CRASH SENSOR
