Audi S7 4K (2019-2024) active accelerator pedal motor Wiring diagrams

7 SPEED TRANSMISSION 8 SPEED TRANSMISSION ABS CONTROL MODULE ACCELERATOR PEDAL MODULE (ON ACCELERATOR PEDAL ASSEMBLY) ACCELERATOR PEDAL POSITION SENSOR ACCELERATOR PEDAL POSITION SENSOR 2 ACTIVE ACCELERATOR PEDAL MOTOR ADAPTIVE CRUISE CONTROL CONTROL MODULE BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU/GRN WIRE BLU/GRY WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRAKE LAMP SWITCH BRAKE PEDAL POSITION SENSOR BRAKE PEDAL SWITCH BRN WIRE BRN/BLU WIRE BRN/RED WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM CRUISE CONTROL SWITCH FUSE 4 FUSE 5 FUSE PANEL A FUSE PANEL F GRN WIRE GRN/BLK WIRE GRN/VIO WIRE GRN/WHT WIRE HEATING ELEMENT FOR ADAPTIVE CRUISE CONTROL RADAR SENSOR HOT AT ALL TIMES HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED IN PLENUM CHAMBER) LASER DISTANCE REGULATION CONTROL MODULE PNK WIRE PNK/WHT WIRE RED/VIO WIRE STEERING COLUMN ELECTRONICS CONTROL MODULE TOWING RECOGNITION CONTROL MODULE TRANSMISSION CONTROL MODULE TRANSMISSION INPUT SPEED SENSOR 1 TRANSMISSION INPUT SPEED SENSOR 2 VIO/RED WIRE YEL/BLU WIRE

ACCELERATOR PEDAL POSITION SENSOR ACCELERATOR PEDAL POSITION SENSOR 2 ACCELERATOR PEDAL MODULE ACTIVE ACCELERATOR PEDAL MOTOR BATTERY INTERRUPT IGNITER BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/WHT WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM ENGINE COMPONENT POWER SUPPLY RELAY ENGINE/MOTOR CONTROL MODULE EXHAUST DOOR CONTROL UNIT FUSE 1 FUSE 2 FUSE 3 FUSE PANEL A GRN WIRE GRN/VIO WIRE GRN/WHT WIRE HOT AT ALL TIMES MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ORG/BRN WIRE PNK WIRE PNK/WHT WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RED/GRY WIRE RED/YEL WIRE VIO/BLK WIRE YEL/BLK WIRE YEL/BLU WIRE
