Headlights circuit, w/o multiple matrix beam w/ high beam control for Audi S6 C8 (2019-2024)
Headlights circuit, w/o multiple matrix beam w/ high beam control (1 of 3)
AUTOMATIC HIGH BEAM BUTTON
BLU WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
FOG LAMP BUTTON
FOG LAMP INDICATOR LAMP
FUSE 3
FUSE 5
FUSE 9
FUSE PANEL D
FUSE PANEL F
GRN WIRE
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
LEFT REAR LEVEL CONTROL SYSTEM SENSOR
LIGHT SWITCH
ORG/BRN WIRE
PARKING BRAKE INDICATOR
REAR FOG LAMP BUTTON
REAR FOG LAMP INDICATOR LAMP
RED/GRN WIRE
RED/WHT WIRE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL/BRN WIRE
YEL/GRY WIRE
Headlights circuit, w/o multiple matrix beam w/ high beam control (2 of 3)
ABS CONTROL MODULE
BRN WIRE
CENTER COUPLING POINT ON INSTRUMENT PANEL
COMPUTER DATA LINES SYSTEM
ELECTRO- MECHANICAL PARKING BRAKE BUTTON
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE
LEFT FRONT HEADLAMP
LEFT FRONT SIDE MARKER LAMP
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLAMP 8-PIN CONNECTOR
LEFT HEADLAMP CURRENT CODING RESISTANCE 1
LEFT HEADLAMP CURRENT CODING RESISTANCE 2
LEFT HEADLAMP CURRENT CODING RESISTANCE 3
LEFT HEADLAMP RANGE CONTROL ADJUSTMENT MOTOR
LEFT HEADLAMP TEMPERATURE SENSOR 1
LEFT HEADLAMP TEMPERATURE SENSOR 2
LEFT HEADLAMP TEMPERATURE SENSOR 3
LEFT HIGH BEAM HEADLAMP
LEFT LED HEADLAMP POWER OUTPUT MODULE 1
LEFT LOW BEAM HEADLAMP
LEFT STATIONARY CORNERING LAMP
ORG/BRN WIRE
PARKING BRAKE BUTTON
PNK WIRE
VIO/WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
Headlights circuit, w/o multiple matrix beam w/ high beam control (3 of 3)
AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR
BRN WIRE
COMPUTER DATA LINES SYSTEM
COUPLING POINT ON ROOF
FUSE 12
FUSE PANEL B
GRY WIRE
HOT AT ALL TIMES
HUMIDITY SENSOR
INTERIOR REAR VIEW MIRROR
LIGHT RECOGNITION SENSOR
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
RAIN/LIGHT RECOGNITION SENSOR
RED WIRE
RIGHT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE
RIGHT FRONT HEADLAMP
RIGHT FRONT SIDE MARKER LAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP 8-PIN CONNECTOR
RIGHT HEADLAMP CURRENT CODING RESISTANCE 1
RIGHT HEADLAMP CURRENT CODING RESISTANCE 2
RIGHT HEADLAMP CURRENT CODING RESISTANCE 3
RIGHT HEADLAMP RANGE CONTROL ADJUSTMENT MOTOR
RIGHT HEADLAMP TEMPERATURE SENSOR 1
RIGHT HEADLAMP TEMPERATURE SENSOR 2
RIGHT HEADLAMP TEMPERATURE SENSOR 3
RIGHT HIGH BEAM HEADLAMP
RIGHT LED HEADLAMP POWER OUTPUT MODULE 1
RIGHT LOW BEAM HEADLAMP
RIGHT STATIONARY CORNERING LAMP
VIO/WHT WIRE
WHT/RED WIRE
