Tire pressure monitoring circuit for Audi S6 C7 (2012-2014)
Tire pressure monitoring circuit
ABS CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
BRN WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DISPLAY UNIT INSTRUMENT CLUSTER CONTROL MODULE
FUSE 10
FUSE CARRIER 2
FUSE PANEL B (LEFT END OF DASH)
GRN/VIO WIRE
HOT AT ALL TIMES
LEFT FRONT TIRE PRESSURE MONITORING ANTENNA
LEFT REAR TIRE PRESSURE MONITORING ANTENNA
ORG/BLK WIRE
ORG/BLU WIRE
ORG/BRN WIRE
RED WIRE
RED/YEL WIRE
RIGHT FRONT TIRE PRESSURE MONITORING ANTENNA
RIGHT REAR TIRE PRESSURE MONITORING ANTENNA
TIRE PRESSURE MONITORING CONTROL MODULE
TIRE PRESSURE MONITORING CONTROL MODULE 2
YEL WIRE
YEL/BRN WIRE
YEL/GRY WIRE
