Multimedia interface circuit, with navigation plus for Audi S6 C7 (2012-2014)

BLK WIRE BLK/BRN WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM DISPLAY CONTROL ASSEMBLY EXTERNAL AUDIO SOURCE CONNECTION FUSE 4 FUSE CARRIER 1 FUSE 2 FUSE PANEL C (RIGHT END OF DASH) GRN WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE FUSE PANEL F FUSE CARRIER 2 (RIGHT REAR OF LUGGAGE COMPT) INFORMATION ELECTRONICS CONTROL MODULE 1 MULTIMEDIA SYSTEM CONTROL HEAD NCA WIRE ORG/ WIRE RED WIRE RED/BLU WIRE RED/GRY WIRE TELEPHONE BASE PLATE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT END OF DASH ) VIO WIRE W/ AUDI MUSIC INTERFACE W/ AUX-IN CONNECTION WHT WIRE WHT/GRN WIRE YEL WIRE YEL/WHT WIRE

1 2 FIBER OPTIC FIBER OPTIC BLK WIRE BLU WIRE BLU/RED WIRE BRN WIRE DISPLAY UNIT BUTTON DVD CHANGER FRONT INFORMATION DISPLAY CONTROL HEAD GRN WIRE GRY/BLU WIRE INFORMATION ELECTRONICS CONTROL MODULE 1 INSTRUMENT CLUSTER CONTROL MODULE MICROPHONE UNIT RIGHT LEFT FRONT FRONT MICROPHONE MICROPHONE MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE RADIO RED/BLU WIRE ROOF ANTENNA GPS ANTENNA SATELLITE ANTENNA TELEPHONE ANTENNA
