Audi S6 C7 (2012-2014) Headlights circuit, with hid without bi-xenon headlights

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FOG INDICATOR LAMP FOG LAMP BUTTON FUSE 6 FUSE 7 FUSE 8 FUSE 9 FUSE CARRIER 2 FUSE 8 FUSE PANEL C (RIGHT END OF DASH) FUSE PANEL D (UNDER LEFT SIDE OF DASH) GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/RED WIRE GRY/YEL WIRE HEADLAMP SWITCH ILLUMINATION BULB HOT AT ALL TIMES INSTRUMENT PANEL, SWITCH ILLUMINATION DIMMER SWITCH LEFT DAYTIME LEFT DAYTIME RUNNING LAMP, PARKING LAMP LED MODULE LEFT FRONT SIDE MARKER LAMP BULB LEFT FRONT TURN SIGNAL BULB LEFT HEADLAMP ASSEMBLY LEFT HEADLAMP BEAM ADJUSTMENT MOTOR LEFT HID HEADLAMP BULB LEFT HID HEADLAMP CONTROL MODULE LEFT LOW BEAM HEADLAMP REFLECTOR MOTOR LEFT STATIONARY CORNERING LAMP LIGHT SWITCH NIGHT VISION SYSTEM BUTTON ORG/BRN WIRE ORG/GRN WIRE PARKING INDICATOR LAMP REAR FOG INDICATOR LAMP REAR FOG LAMP BUTTON RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/YEL WIRE RUNNING LAMP, PARKING LAMP CONTROL MODULE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT END OF DASH ) VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE

BLK WIRE BLK/BRN WIRE BLK/GRN WIRE BLU WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE CARRIER 1 FUSE 8 FUSE PANEL C (RIGHT END OF DASH) GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE HEADLAMP RANGE CONTROL MODULE (LEFT END OF DASH) HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED LEFT FRONT LEVEL CONTROL SYSTEM SENSOR ORG/BRN WIRE ORG/GRY WIRE PNK WIRE RED WIRE RIGHT DAYTIME RIGHT DAYTIME RUNNING LAMP, PARKING LAMP LED MODULE RIGHT FRONT SIDE MARKER LAMP BULB RIGHT FRONT TURN SIGNAL BULB RIGHT HEADLAMP ASSEMBLY RIGHT HEADLAMP BEAM ADJUSTMENT MOTOR RIGHT HID HEADLAMP BULB RIGHT HID HEADLAMP CONTROL MODULE RIGHT LOW BEAM HEADLAMP REFLECTOR MOTOR RIGHT STATIONARY CORNERING LAMP RUNNING LAMP, PARKING LAMP CONTROL MODULE VIO WIRE VIO/BRN WIRE VIO/RED WIRE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
