Ground distribution circuit for Audi S6 C7 (2012-2014)

2.0L TURBO BRN WIRE COOLANT RECIRCULATION PUMP, OIL LEVEL THERMAL SENSOR, SUPPRESSOR DATA LINK CONNECTOR ENGINE CONTROL MODULE GRN WIRE IGNITION COILS 1, 2, 3, 4 W/ POWER OUTPUT STAGE INSTRUMENT CLUSTER CONTROL MODULE SUBFRAME MOUNT CONTROL MODULE WINDSHIELD PROJECTION HEAD UP DISPLAY CONTROL MODULE

4.0L TURBO BRN WIRE BRN/WHT WIRE DRIVER BACKREST HEATING ELEMENT/ BOLSTER HEATER ENGINE CONTROL MODULE, SUPPRESSOR, SECONDARY AIR INJECTION PUMP MOTOR IGNITION COILS 1, 2, 3, 4 W/ POWER OUTPUT STAGE IGNITION COILS 5, 6, 7, 8 W/ POWER OUTPUT STAGE LEFT FRONT SEAT VENTILATION CONTROL MODULE ROOF SHADE CONTROL MODULE, POWER SUNROOF CONTROL MODULE SUBWOOFER (IF EQUIPPED) TRANSMISSION CONTROL MODULE WHT WIRE

BLK WIRE BRN WIRE FM FREQUENCY FILTER (IN NEGATIVE WIRE) HIGH-MOUNTED BRAKE LAMP BULB (W/ INSULTING/ HEAT ABSORBING GLASS)

4.0L TURBO BATTERY MONITORING CONTROL MODULE BLK WIRE BRN WIRE COOLING FAN CONTROL MODULE, COOLING FAN CONTROL MODULE 2 (EXCEPT 2.0L TURBO) POWER STEERING CONTROL MODULE REAR CIGARETTE LIGHTER, CIGARETTE LIGHTER (W/ SMOKING PACKAGE),

ABS CONTROL MODULE ACTIVE STEERING CONTROL MODULE SHIELD ALL WHEEL DRIVE CONTROL MODULE, REAR LID OPENER CONTROL MODULE (IF EQUIPPED) BLK WIRE BRN WIRE BRN/GRN WIRE BRN/WHT WIRE DISTANCE REGULATION CONTROL MODULE, DISTANCE REGULATION CONTROL MODULE 2 IGNITION COILS 4, 5, 6 W/ POWER OUTPUT STAGE ROOF ANTENNA SHIELD, ROOF ANTENNA SUPPRESSOR
