Heated and cooled cup holder circuit for Audi S6 C7 (2012-2014)

Heated and cooled cup holder circuit

Get access

BLK WIRE BLU WIRE BRN WIRE CUP HOLDER COOLING ELEMENT BUTTON CUP HOLDER HEATING ELEMENT BUTTON CUP HOLDER W/ HEATING, COOLING ELEMENT FUSE FUSE CARRIER FUSE CARRIER FUSE FUSE PANEL F (RIGHT REAR OF LUGGAGE COMPT) GRN WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT W/ SOCKETS RELAY ENERGIZED RED WIRE RED/GRN WIRE RED/YEL WIRE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT END OF DASH ) WHT WIRE YEL WIRE
