Audi S6 C7 (2012-2014) w/ led taillamps Wiring diagrams

This page contains all the electrical diagrams for the component. w/ led taillamps, in which he is found in the car Audi S6 C7 (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram w/ led taillamps (1 of 3)

Wiring diagram w/ led taillamps for Audi S6 C7 (2012-2014)

Get access

7 SPEED A/T 8 SPEED A/T CVT AUTOMATIC DIMMING INTERIOR REARVIEW MIRROR BACKUP BLK WIRE BLK/BLU WIRE BLK/VIO WIRE BLU WIRE BRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT) COMPUTER DATA LINES SYSTEM FUSE 8 FUSE CARRIER FUSE 7 FUSE PANEL F (RIGHT REAR OF LUGGAGE COMPT) GRN/VIO WIRE GRY/WHT WIRE HOT AT ALL TIMES LEVER ASSEMBLY) ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/WHT WIRE RED/YEL WIRE SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE (BASE OF SHIFT TRANSMISSION CONTROL MODULE (TCM) (UNDER TRANSMISSION OIL PAN) VIO WIRE W/ LED TAILLAMPS W/O HIGH BEAM ASSIST W/O LED TAILLAMPS WHT WIRE YEL WIRE

Go to component: -> Backup lamps circuit -> W/ LED TAILLAMPS

Wiring diagram w/ led taillamps (2 of 3)

Wiring diagram w/ led taillamps for Audi S6 C7 (2012-2014)

Get access

BACKUP LAMPS CIRCUIT BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT) COMPUTER DATA LINES SYSTEM GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/WHT WIRE GRY/YEL WIRE HIGH-MOUNTED BRAKE LAMP BULB LAMP BULB LAMP/ TURN SIGNAL BULB 3 LAMP/ TURN SIGNAL/ TAILLAMP BULB 2 LEFT LEFT BACKUP LAMP BULB LEFT REAR SIDE MARKER LEFT BRAKE LEFT BRAKE LAMP/ TURN SIGNAL BULB LEFT BRAKE LAMP/ TURN SIGNAL BULB 2 LEFT BRAKE LAMP/ TURN SIGNAL/ TAILLAMP BULB LEFT BRAKE/ BACKUP TAILLAMP LAMP BULB BULB LEFT BRAKE/ REAR PARKING/ FOG LAMP BULB LEFT REAR TAILLAMP ASSEMBLY 2 LEFT LEFT BRAKE/ REAR TAIL TURN LAMP SIGNAL BULB BULB 2 LEFT REAR FOG LAMP BULB LEFT REAR TAILLAMP ASSEMBLY 1 LEFT REAR TAILLAMP ASSEMBLY 2 ORG/BRN WIRE ORG/GRN WIRE RED/BLK WIRE RED/BLU WIRE W/ LED TAILLAMPS W/O LED TAILLAMPS WHT WIRE WHT/BLU WIRE YEL WIRE

Go to component: -> Exterior lamps circuit (4 of 5) -> W/ LED TAILLAMPS

Wiring diagram w/ led taillamps (3 of 3)

Wiring diagram w/ led taillamps for Audi S6 C7 (2012-2014)

Get access

4.0L 3.0L 2.0L BACKUP LAMPS CIRCUIT BLK WIRE BLK/GRN WIRE BLU WIRE BRAKE LIGHT SWITCH (ON BRAKE PEDAL ASSEMBLY) BRN WIRE BULB COMPUTER DATA LINES SYSTEM FUSE CARRIER FUSE FUSE PANEL B (LEFT END OF DASH) GRN WIRE GRY WIRE GRY/BLU WIRE GRY/WHT WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE LEFT LICENSE PLATE LAMP LEFT TURN IND ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE REAR PARKING/ FOG LAMP BULB RED WIRE RED/BLK WIRE RED/VIO WIRE RIGHT BACKUP LAMP RIGHT BRAKE LAMP/ TURN SIGNAL BULB 3 RIGHT BRAKE LAMP/ TURN SIGNAL/ TAILLAMP BULB RIGHT BRAKE/ RIGHT BRAKE/ TAIL LAMP BULB 2 RIGHT LICENSE PLATE LAMP RIGHT REAR FOG LAMP BULB RIGHT REAR SIDE MARKER LAMP BULB RIGHT REAR TAILLAMP ASSEMBLY 1 RIGHT REAR TAILLAMP ASSEMBLY 2 RIGHT REAR TURN SIGNAL BULB RIGHT RIGHT BRAKE BACKUP LAMP/ LAMP TURN BULB SIGNAL/ TAILLAMP BULB 2 RIGHT RIGHT BRAKE LAMP/ BRAKE LAMP/ TURN TURN SIGNAL BULB SIGNAL BULB 2 RIGHT TURN IND TAILLAMP BULB VIO WIRE W/ LED TAILLAMPS W/O LED TAILLAMPS WHT WIRE YEL WIRE

Go to component: -> Exterior lamps circuit (5 of 5) -> W/ LED TAILLAMPS
