Audi S6 C7 (2012-2014) vertical motor wiring diagram
This page shows the only wiring diagram for the component.vertical motor, which is found in the car Audi S6 C7 (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
vertical motor wiring diagram (1 of 1)
28 29 PNK WIRE
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLU WIRE
BLU/RED WIRE
BRN/WHT WIRE
DAY/NIGHT
DAY/NIGHT (IF EQUIPPED)
DRIVER'S SIDE EXTERIOR MIRROR
FOLDING
FOLDING MOTOR (IF EQUIPPED)
FRONT PASSENGER'S SIDE EXTERIOR MIRROR
FUSE 4
FUSE 6
FUSE CARRIER 1
FUSE CARRIER 2
FUSE PANEL B (LEFT END OF DASH)
FUSE PANEL F (RIGHT REAR OF LUGGAGE COMPT)
GRY/WHT WIRE
GRY/YEL WIRE
HEATER
HORIZONTAL MOTOR
HORIZONTAL SENSOR (IF EQUIPPED)
HOT AT ALL TIMES
LANE CHANGE
MOTOR
NAVIGATION SYSTEM
PNK WIRE
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
TURN SIGNAL
VERTICAL MOTOR
VERTICAL SENSOR (IF EQUIPPED)
VIO WIRE
WHT WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Memory mirrors circuit (2 of 2) -> VERTICAL MOTOR
