Audi S6 C7 (2012-2014) subframe mount control module Wiring diagram
This page shows the only wiring diagram for the component.subframe mount control module, which is found in the car Audi S6 C7 (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram subframe mount control module (1 of 1)
2.0L TURBO
BRN WIRE
COOLANT RECIRCULATION PUMP, OIL LEVEL THERMAL SENSOR, SUPPRESSOR
DATA LINK CONNECTOR
ENGINE CONTROL MODULE
GRN WIRE
IGNITION COILS 1, 2, 3, 4 W/ POWER OUTPUT STAGE
INSTRUMENT CLUSTER CONTROL MODULE
SUBFRAME MOUNT CONTROL MODULE
WINDSHIELD PROJECTION HEAD UP DISPLAY CONTROL MODULE
Go to component: -> Ground distribution circuit (1 of 5) -> SUBFRAME MOUNT CONTROL MODULE
