Audi S6 C7 (2012-2014) steering column vertical adjustment motor/sensor Wiring diagram

This page shows the only wiring diagram for the component.steering column vertical adjustment motor/sensor, which is found in the car Audi S6 C7 (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram steering column vertical adjustment motor/sensor (1 of 1)

Wiring diagram steering column vertical adjustment motor/sensor for Audi S6 C7 (2012-2014)

Get access

BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DISPLAY UNIT FUSE CARRIER FUSE 7 FUSE PANEL C (RIGHT END OF DASH) GRN WIRE GRN/BLK WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL MODULE ORG/BLU WIRE ORG/BRN WIRE POWER ADJUSTABLE STEERING COLUMN CONTROL MODULE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE STEERING COLUMN ADJUSTMENT SWITCH STEERING COLUMN VERTICAL ADJUSTMENT MOTOR/SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT END OF DASH ) VIO/RED WIRE VIO/WHT WIRE

Go to component: -> Power steering column circuit -> STEERING COLUMN VERTICAL ADJUSTMENT MOTOR/SENSOR
