Audi S6 C7 (2012-2014) right rear door contact switch Wiring diagrams

This page contains all the electrical diagrams for the component. right rear door contact switch, in which he is found in the car Audi S6 C7 (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram right rear door contact switch (1 of 2)

Wiring diagram right rear door contact switch for Audi S6 C7 (2012-2014)

Get access

BRN WIRE BRN/BLU WIRE CONTACT SWITCH GRN WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/VIO WIRE LEFT REAR CENTRAL LOCKING SYSTEM ACTUATOR LEFT REAR CENTRAL LOCKING SYSTEM MOTOR LEFT REAR CHILD SAFETY LEFT REAR CHILD SAFETY LOCK CONTACT SWITCH LEFT REAR CHILD SAFETY LOCK MOTOR LEFT REAR CLOSING ASSIST MOTOR LEFT REAR DOOR CONTACT SWITCH LOCK CONTACT SWITCH RED/BLU WIRE RIGHT REAR CENTRAL LOCKING LOCK UNIT (W/ DOOR CLOSING AID) RIGHT REAR CENTRAL LOCKING LOCK UNIT (W/O DOOR CLOSING AID) RIGHT REAR CENTRAL LOCKING SYSTEM ACTUATOR RIGHT REAR CENTRAL LOCKING SYSTEM MOTOR RIGHT REAR CHILD RIGHT SAFETY REAR LOCK DOOR CONTACT CONTACT SWITCH SWITCH RIGHT REAR CHILD SAFETY LOCK RIGHT REAR CHILD SAFETY LOCK MOTOR RIGHT REAR CONTACT SWITCH RIGHT REAR DOOR CONTACT SWITCH VIO WIRE VIO/YEL WIRE W/ DOOR CLOSING AID W/O DOOR CLOSING AID WHT/BLU WIRE WHT/YEL WIRE

Go to component: -> Anti-theft circuit (3 of 6) -> RIGHT REAR DOOR CONTACT SWITCH

Wiring diagram right rear door contact switch (2 of 2)

Wiring diagram right rear door contact switch for Audi S6 C7 (2012-2014)

Get access

BRN WIRE BRN/BLU WIRE CONTACT SWITCH GRN WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/VIO WIRE LEFT REAR CENTRAL LOCKING SYSTEM ACTUATOR LEFT REAR CENTRAL LOCKING SYSTEM MOTOR LEFT REAR CHILD SAFETY LEFT REAR CHILD SAFETY LOCK CONTACT SWITCH LEFT REAR CHILD SAFETY LOCK MOTOR LEFT REAR CLOSING ASSIST MOTOR LEFT REAR DOOR CONTACT SWITCH LOCK CONTACT SWITCH RED/BLU WIRE RIGHT REAR CENTRAL LOCKING LOCK UNIT (W/ DOOR CLOSING AID) RIGHT REAR CENTRAL LOCKING LOCK UNIT (W/O DOOR CLOSING AID) RIGHT REAR CENTRAL LOCKING SYSTEM ACTUATOR RIGHT REAR CENTRAL LOCKING SYSTEM MOTOR RIGHT REAR CHILD RIGHT SAFETY REAR LOCK DOOR CONTACT CONTACT SWITCH SWITCH RIGHT REAR CHILD SAFETY LOCK RIGHT REAR CHILD SAFETY LOCK MOTOR RIGHT REAR CONTACT SWITCH RIGHT REAR DOOR CONTACT SWITCH VIO WIRE VIO/YEL WIRE W/ DOOR CLOSING AID W/O DOOR CLOSING AID WHT/BLU WIRE WHT/YEL WIRE

Go to component: -> Power door locks circuit (3 of 6) -> RIGHT REAR DOOR CONTACT SWITCH
