Audi S6 C7 (2012-2014) rear temp- erature selection potentio meter Wiring diagram
This page shows the only wiring diagram for the component.rear temp- erature selection potentio meter, which is found in the car Audi S6 C7 (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear temp- erature selection potentio meter (1 of 1)
BLU WIRE
BRN WIRE
BUTTON
BUTTON FOG LAMP
CENTER INSTRUMENT PANEL VENT ILLUMINATION BULB
CIGARETTE LIGHTER ILLUMINATION BULB (W/ SMOKING PACKAGE)
COMPUTER DATA LINES SYSTEM
EMERGENCY FLASHER INDICATOR LAMP
FOG LAMP
FUSE
FUSE 8
FUSE 8 PANEL D (UNDER LEFT SIDE OF DASH)
FUSE CARRIER 2
FUSE PANEL C (RIGHT END OF DASH)
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/YEL WIRE
HEADLAMP
HOT AT ALL TIMES
ILLUMINATION
ILLUMINATION BULB
INDICATOR LAMP
INDICATOR LAMP REAR FOG
INSTRUMENT
LAMP
LEFT INSTRUMENT PANEL VENT ILLUMINATION BULB
LEFT REAR AIR
LEFT SEAT HEATING BUTTON
LIGHT SWITCH
NIGHT VISION
ORG/BRN WIRE
ORG/GRN WIRE
PANEL)
PARKING LAMP
REAR CENTER AIR VENT ILLUMINATION BULB
REAR CIGARETTE LIGHTER ILLUMINATION BULB
REAR FOG LAMP
REAR TEMP- ERATURE SELECTION POTENTIO METER
RED/YEL WIRE
SOCKET ILLUMINATION BULB
SWITCH
SWITCH DIMMER
SWITCH ILLUMINATION BULB
SYSTEM BUTTON
VALET PARKING INDICATOR LAMP
VALET PARKING LOCK BUTTON
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT END OF DASH )
VENT ILLUMINATION BULB
VIO WIRE
WHT WIRE
Go to component: -> Instrument illumination circuit (1 of 3) -> REAR TEMP- ERATURE SELECTION POTENTIO METER
