Audi S6 C7 (2012-2014) rear parking/ fog lamp bulb Wiring diagram
This page shows the only wiring diagram for the component.rear parking/ fog lamp bulb, which is found in the car Audi S6 C7 (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear parking/ fog lamp bulb (1 of 1)
4.0L 3.0L 2.0L
BACKUP LAMPS CIRCUIT
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BRAKE LIGHT SWITCH (ON BRAKE PEDAL ASSEMBLY)
BRN WIRE
BULB
COMPUTER DATA LINES SYSTEM
FUSE CARRIER FUSE
FUSE PANEL B (LEFT END OF DASH)
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
LEFT LICENSE PLATE LAMP
LEFT TURN IND
ORG/BLK WIRE
ORG/BLU WIRE
ORG/BRN WIRE
REAR PARKING/ FOG LAMP BULB
RED WIRE
RED/BLK WIRE
RED/VIO WIRE
RIGHT BACKUP LAMP
RIGHT BRAKE LAMP/ TURN SIGNAL BULB 3
RIGHT BRAKE LAMP/ TURN SIGNAL/ TAILLAMP BULB
RIGHT BRAKE/
RIGHT BRAKE/ TAIL LAMP BULB 2
RIGHT LICENSE PLATE LAMP
RIGHT REAR FOG LAMP BULB
RIGHT REAR SIDE MARKER LAMP BULB
RIGHT REAR TAILLAMP ASSEMBLY 1
RIGHT REAR TAILLAMP ASSEMBLY 2
RIGHT REAR TURN SIGNAL BULB
RIGHT RIGHT BRAKE BACKUP LAMP/ LAMP TURN BULB SIGNAL/ TAILLAMP BULB 2
RIGHT RIGHT BRAKE LAMP/ BRAKE LAMP/ TURN TURN SIGNAL BULB SIGNAL BULB 2
RIGHT TURN IND
TAILLAMP BULB
VIO WIRE
W/ LED TAILLAMPS
W/O LED TAILLAMPS
WHT WIRE
YEL WIRE
Go to component: -> Exterior lamps circuit (5 of 5) -> REAR PARKING/ FOG LAMP BULB
