Audi S6 C7 (2012-2014) left front tire pressure monitoring antenna Wiring diagram

This page shows the only wiring diagram for the component.left front tire pressure monitoring antenna, which is found in the car Audi S6 C7 (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram left front tire pressure monitoring antenna (1 of 1)

Wiring diagram left front tire pressure monitoring antenna for Audi S6 C7 (2012-2014)

Get access

ABS CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) BRN WIRE BRN/GRN WIRE COMPUTER DATA LINES SYSTEM DISPLAY UNIT INSTRUMENT CLUSTER CONTROL MODULE FUSE 10 FUSE CARRIER 2 FUSE PANEL B (LEFT END OF DASH) GRN/VIO WIRE HOT AT ALL TIMES LEFT FRONT TIRE PRESSURE MONITORING ANTENNA LEFT REAR TIRE PRESSURE MONITORING ANTENNA ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE RED WIRE RED/YEL WIRE RIGHT FRONT TIRE PRESSURE MONITORING ANTENNA RIGHT REAR TIRE PRESSURE MONITORING ANTENNA TIRE PRESSURE MONITORING CONTROL MODULE TIRE PRESSURE MONITORING CONTROL MODULE 2 YEL WIRE YEL/BRN WIRE YEL/GRY WIRE

Go to component: -> Tire pressure monitoring circuit -> LEFT FRONT TIRE PRESSURE MONITORING ANTENNA
