Audi S6 C7 (2012-2014) front passenger's seat angle adjustment motor Wiring diagram

This page shows the only wiring diagram for the component.front passenger's seat angle adjustment motor, which is found in the car Audi S6 C7 (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram front passenger's seat angle adjustment motor (1 of 1)

Wiring diagram front passenger's seat angle adjustment motor for Audi S6 C7 (2012-2014)

Get access

ANGLE BACKREST BLK WIRE BLU WIRE BRN WIRE FORWARD /BACK FRONT PASSENGER BACKREST ADJUSTMENT MOTOR FRONT PASSENGER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 FRONT PASSENGER SEAT HEIGHT ADJUSTMENT MOTOR FRONT PASSENGER SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR FRONT PASSENGER SEAT LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTOR FRONT PASSENGER'S SEAT ADJUSTMENT CONTROL HEAD FRONT PASSENGER'S SEAT ANGLE ADJUSTMENT MOTOR FRONT PASSENGER'S SEAT FORWARD/BACK ADJUSTMENT MOTOR FRONT PASSENGER'S SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH GRN WIRE HEIGHT HOT AT ALL TIMES RED WIRE RED/BLK WIRE WHT WIRE YEL WIRE

Go to component: -> Power seats circuit -> FRONT PASSENGER'S SEAT ANGLE ADJUSTMENT MOTOR
