Audi S6 C7 (2012-2014) driver's side outside folding mirror Wiring diagram

This page shows the only wiring diagram for the component.driver's side outside folding mirror, which is found in the car Audi S6 C7 (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram driver's side outside folding mirror (1 of 1)

Wiring diagram driver's side outside folding mirror for Audi S6 C7 (2012-2014)

Get access

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BRN WIRE CLIMATRONIC CONTROL MODULE COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT) COMPUTER DATA LINES SYSTEM DRIVER'S DOOR CONTROL MODULE (IN DRIVER'S FRONT DOOR) DRIVER'S SIDE OUTSIDE FOLDING MIRROR FM FREQUENCY FILTER (IN NEGATIVE WIRE) FM FREQUENCY FILTER (IN POSITIVE WIRE) FRONT PASSENGER'S DOOR CONTROL MODULE (IN FRONT PASSENGER'S FRONT DOOR) FUSE FUSE 3 CARRIER 5 FUSE FUSE 4 CARRIER FUSE FUSE 6 CARRIER 1 FUSE PANEL B (LEFT END OF DASH) FUSE PANEL F (RIGHT REAR OF LUGGAGE COMPT) HEATED DRIVER EXTERIOR REARVIEW MIRROR HOT AT ALL TIMES MIRRORS SYSTEM ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE REAR WINDOW DEFOGGER REAR WINDOW DEFOGGER RELAY (ON RELAY & FUSE PANEL F) RED/BLK WIRE RED/GRN WIRE RED/YEL WIRE WHT WIRE WHT/RED WIRE WINDSHIELD ANTENNA SUPPRESSION FILTER

Go to component: -> Defoggers circuit -> DRIVER'S SIDE OUTSIDE FOLDING MIRROR
