Audi S6 C7 (2012-2014) cooling oil valve Wiring diagram
This page shows the only wiring diagram for the component.cooling oil valve, which is found in the car Audi S6 C7 (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cooling oil valve (1 of 1)
AUTOMATIC TRANSMISSION HYDRAULIC PRESSURE SENSOR 1
AUTOMATIC TRANSMISSION HYDRAULIC PRESSURE SENSOR 2
BLK WIRE
BLK/BLU WIRE
BLK/VIO WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BRN WIRE
CLUTCH OIL TEMPERATURE SENSOR
COMPUTER DATA LINES SYSTEM
COOLING OIL VALVE
DRIVE POSITION SENSOR
DSG TRANSMISSION MECHATRONIC
FUSE
FUSE 13
FUSE PANEL A (IN LEFT
GEAR POSITION DISTANCE SENSOR 1
GEAR POSITION DISTANCE SENSOR 2
GEAR POSITION DISTANCE SENSOR 3
GEAR POSITION DISTANCE SENSOR 4
GRN/VIO WIRE
GRN/YEL WIRE
GRY WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
MAIN PRESSURE VALVE
ORG/BLK WIRE
ORG/BRN WIRE
PLENUM CHAMBER E-BOX)
RED WIRE
SUB-TRANSMISSION 1 VALVE 1
SUB-TRANSMISSION 1 VALVE 2
SUB-TRANSMISSION 1 VALVE 3
SUB-TRANSMISSION 1 VALVE 4
SUB-TRANSMISSION 2 VALVE 1
SUB-TRANSMISSION 2 VALVE 2
SUB-TRANSMISSION 2 VALVE 3
SUB-TRANSMISSION 2 VALVE 4
TEMPERATURE SENSOR (IN CONTROL MODULE)
TRANSMISSION CONTROL MODULE
TRANSMISSION INPUT SPEED SENSOR 1
TRANSMISSION INPUT SPEED SENSOR 2
TRANSMISSION INPUT SPEED SENSOR 3
YEL/GRN WIRE
Go to component -> A/t circuit (1 of 3) -> COOLING OIL VALVE
