Audi S6 C7 (2012-2014) bolster heater Wiring diagrams

This page contains all the electrical diagrams for the component. bolster heater, in which he is found in the car Audi S6 C7 (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram bolster heater (1 of 2)

Wiring diagram bolster heater for Audi S6 C7 (2012-2014)

Get access

BACKREST BOLSTER HEATER BACKREST HEATING ELEMENT BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BOLSTER HEATER BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER'S BACKREST HEATING ELEMENT, BOLSTER HEATER DRIVER'S SEAT BACKREST BLOWER FAN DRIVER'S SEAT BACKREST BLOWER FAN 2 DRIVER'S SEAT CUSHION BLOWER FAN DRIVER'S SEAT CUSHION BLOWER FAN 2 DRIVER'S SEAT HEATER LEFT FRONT SEAT TEMP SENSOR FRONT PASSENGER MEMORY SEAT CONTROL MODULE FRONT PASSENGER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 FRONT PASSENGER'S BACKREST HEATING ELEMENT FRONT PASSENGER'S SEAT BACKREST BLOWER FAN FRONT PASSENGER'S SEAT BACKREST BLOWER FAN 2 FRONT PASSENGER'S SEAT CUSHION BLOWER FAN FRONT PASSENGER'S SEAT CUSHION BLOWER FAN 2 FRONT PASSENGER'S SEAT HEATER RIGHT FRONT SEAT TEMP SENSOR GRN WIRE GROUND DISTRIBUTION SYSTEM HOT AT ALL TIMES MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE ORG/BRN WIRE ORG/GRN WIRE POWER DISTRIBUTION SYSTEM RED WIRE RED/BLK WIRE RED/YEL WIRE SEAT BOLSTER HEATER SEAT HEATER W/ COMFORT SEATS W/O COMFORT SEATS WHT WIRE YEL WIRE

Go to component: -> Heated seats circuit, with memory -> BOLSTER HEATER

Wiring diagram bolster heater (2 of 2)

Wiring diagram bolster heater for Audi S6 C7 (2012-2014)

Get access

BACKREST BOLSTER HEATER BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BOLSTER HEATER BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER BACKREST HEATING ELEMENT/ BOLSTER HEATER DRIVER SEAT BACKREST BLOWER FAN DRIVER SEAT BACKREST BLOWER FAN 2 DRIVER SEAT CUSHION BLOWER FAN DRIVER SEAT CUSHION BLOWER FAN 2 FRONT PASSENGER SEAT BACKREST BLOWER FAN FRONT PASSENGER SEAT BACKREST BLOWER FAN 2 FRONT PASSENGER SEAT CUSHION BLOWER FAN FRONT PASSENGER SEAT CUSHION BLOWER FAN 2 FUSE CARRIER FUSE 9 FUSE PANEL F (RIGHT REAR OF LUGGAGE COMPT) GRN WIRE HEATING ELEMENT HEATING ELEMENT FRONT PASSENGER BACKREST HEATING ELEMENT HOT AT ALL TIMES HOT AT ALL TIMES FUSE PANEL D FUSE 10 (UNDER LEFT SIDE OF DASH) LEFT FRONT SEAT HEATER/SENSOR LEFT FRONT SEAT VENTILATION CONTROL MODULE ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/YEL WIRE RIGHT FRONT SEAT HEATER/ SENSOR RIGHT FRONT SEAT VENTILATION CONTROL MODULE SEAT TEMPERATURE SENSOR SIDE BOLSTER HEATER SIDE HEATING ELEMENT BOLSTER HEATER TEMPERATURE SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT END OF DASH ) VIO WIRE VIO/WHT WIRE W/ AUXILIARY HEATER WHT WIRE YEL WIRE

Go to component: -> Seat ventilation circuit -> BOLSTER HEATER
