Rear camera circuit for Audi S6 C6 facelift (2008-2011)
Rear camera circuit
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
EARLY LATE PRODUCTION PRODUCTION
FUSE HOLDER 2 FUSE 1
FUSE PANEL SF
GRN/RED WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
PINS: 1-38 (NOT USED) 39 40 41 42 43 44 45 46 47 48 PINS: 49-54 (NOT USED)
REAR VIEW CAMERA
REAR VIEW CAMERA SYSTEM CONTROL MODULE
RED WIRE
RED/YEL WIRE
TV TUNER (EARLY PRODUCTION)
YEL WIRE
