Car Wiring Diagrams for Access/start circuit for Audi S6 C6 facelift (2008-2011)

3.2L, 3.0L ENGINE 4.2L ENGINE 5.2L ENGINE ACCESS/START AUTHORIZATION BUTTON ACCESS/START CONTROL MODULE (BASE OF STEERING COLUMN) BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/RED WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 133 FUSE FUSE PANEL HOLDER FUSE 1 SC FUSE PANEL SB FUSE 42 GRN/YEL WIRE GRY/BLU WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER SYSTEM MAIN FUSE PANEL (E-BOX) (IN RIGHT PLENUM CHAMBER E-BOX) ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/YEL WIRE TRANSMISSION CONTROL MODULE (TCM) (UNDER TRANSMISSION OIL PAN) W/ CVT W/O CVT

9 POSITION RELAY & FUSE PANEL (UNDER LEFT SIDE OF DASH) ACCESS/START AUTHORIZATION SWITCH AMPLIFIER 2 ANTENNA BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/YEL WIRE DOOR LOCKS SYSTEM DRIVER'S ACCESS/START AUTHORIZATION ANTENNA (IN LEFT REAR DOOR) FRONT PASSENGER'S ACCESS/START AUTHORIZATION ANTENNA (REAR OF LUGGAGE COMPT) GRN WIRE GRN/BLU WIRE GRN/YEL WIRE GRY WIRE GRY/GRN WIRE GRY/RED WIRE INTERIOR ACCESS/ START AUTHORIZATION ANTENNA 1 KEYLESS ACCESS AUTHORIZATION ANTENNA READER (ABOVE GLOVE BOX) LUGGAGE COMPARTMENT ACCESS/START AUTHORIZATION ANTENNA NCA WIRE POWER DISTRIBUTION SYSTEM POWER SUPPLY RELAY POWER SUPPLY RELAY (TERMINAL 15) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/YEL WIRE STARTER RELAY STARTER RELAY 2 STARTING/ CHARGING SYSTEM TRANSMISSION SYSTEM WHT WIRE YEL WIRE YEL/GRY WIRE
