Audi S6 C6 facelift (2008-2011) front passenger's door central locking lock unit Wiring diagram

This page shows the only wiring diagram for the component.front passenger's door central locking lock unit, which is found in the car Audi S6 C6 facelift (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram front passenger's door central locking lock unit (1 of 1)

Wiring diagram front passenger's door central locking lock unit for Audi S6 C6 facelift (2008-2011)

Get access

"B" PILLAR) BLK WIRE BLU WIRE BLU/GRN WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM EXCEPT LATE PRODUCTION W/O DOOR CLOSING ASSISTANCE FRONT PASSENGER'S DOOR CENTRAL LOCKING LOCK UNIT FRONT PASSENGER'S DOOR CONTROL MODULE (IN FRONT PASSENGER'S DOOR) FUSE FUSE FUSE 6 HOLDER SC FUSE PANEL FUSE PANEL FUSE 10 HOLDER SF GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES LATE PRODUCTION W/O DOOR CLOSING ASSISTANCE ORG/BRN WIRE ORG/GRN WIRE RED/BLU WIRE RED/YEL WIRE RIGHT REAR DOOR CENTRAL LOCKING LOCK UNIT RIGHT REAR DOOR CONTROL MODULE (IN RIGHT REAR DOOR) TRUNK LOCK ALARM/CENTRAL LOCKING SWITCH W/ CHILD SAFETY LOCK WHT/BLU WIRE WHT/YEL WIRE

Go to component: -> Anti-theft circuit (2 of 2) -> FRONT PASSENGER'S DOOR CENTRAL LOCKING LOCK UNIT
