Audi S6 C6 (2006-2008) Radio circuit, with 6-channel dsp radio

BLK WIRE BLK/YEL WIRE BLU/GRN WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DIGITAL SOUND SYSTEM CONTROL MODULE (LEFT REAR OF LUGGAGE COMPT) FUSE FUSE 1 GRN WIRE GRN/VIO WIRE HOT AT ALL TIMES LEFT FRONT BASS SPEAKER LEFT FRONT MIDRANGE SPEAKER LEFT FRONT TREBLE SPEAKER LEFT REAR MID/LOW RANGE LOUD SPEAKER LEFT REAR TREBLE SPEAKER MICROPHONE UNIT (IF EQUIPPED) NCA WIRE RED WIRE RED/BLU WIRE RED/VIO WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT MIDRANGE SPEAKER RIGHT FRONT TREBLE SPEAKER RIGHT REAR MID/LOW RANGE LOUD SPEAKER RIGHT REAR TREBLE SPEAKER SOUND SYSTEM (MOST DATA BUS CIRCUIT) TELEPHONE TRANSCEIVER WHT/BLK WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE

AMPLIFIER ANTENNA BLK WIRE BLU WIRE BRN WIRE CD CHANGER UNIT MEDIA PLAYER POSITION 2, OR MINI DISC PLAYER CD CHANGER UNIT OR MEDIA PLAYER, POSITION 1 COMPUTER DATA LINES SYSTEM FUSE FUSE 12 FUSE 2 FUSE 9 GRN WIRE GRN/VIO WIRE HOT AT ALL TIMES NCA WIRE RADIO RADIO/TELEPHONE/ NAVIGATION ANTENNA RED WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE SATELLITE RADIO SOUND SYSTEM (MOST DATA BUS CIRCUIT) SPEECH INPUT CONTROL MODULE (IF EQUIPPED) YEL WIRE
