Cooling fan circuit for Audi S6 C6 (2006-2008)

3.2L 4.2L ENGINE 5.2L ENGINE 3.2L ENGINE 4.2L, 5.2L AFTER-RUN COOLANT PUMP BRN WIRE ENGINE CONTROL MODULE (ECM) (3.2L) ENGINE CONTROL MODULE (ECM) (4.2L, 5.2L) ENGINE CONTROLS SYSTEM FUSE 104 FUSE 3 FUSE 42 FUSE 9 FUSE PANEL A GRY/BLU WIRE HOT AT ALL TIMES HOT W/ ECM RELAY ENERGIZED MAIN FUSE PANEL (E-BOX) (IN RIGHT PLENUM CHAMBER E-BOX) POWER DISTRIBUTION SYSTEM RED WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY HOLDER (E-BOX) (IN LEFT PLENUM CHAMBER E-BOX) SUPPRESSOR
