Audi S6 C6 (2006-2008) w/ bose premium w/ bose wiring diagram
This page shows the only wiring diagram for the component.w/ bose premium w/ bose, which is found in the car Audi S6 C6 (2006-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
w/ bose premium w/ bose wiring diagram (1 of 1)
CD CHANGER UNIT MEDIA PLAYER POSITION 2, OR MINI DISC PLAYER
CD CHANGER UNIT OR MEDIA PLAYER, POSITION 1
DATA BUS ON BOARD DIAGNOSTIC INTERFACE (ABOVE GLOVE BOX)
DIGITAL SOUND SYSTEM CONTROL MODULE (LEFT REAR OF LUGGAGE COMPT)
FRONT INFORMATION DISPLAY CONTROL HEAD CONTROL MODULE (ABOVE GLOVE BOX)
LWL IN
LWL OUT
NAVIGATION SYSTEM W/ CD DRIVE CONTROL MODULE (LEFT REAR OF LUGGAGE COMPT)
NCA WIRE
RADIO
SATELLITE RADIO
TELEPHONE TRANSCEIVER
W/ BOSE PREMIUM W/ BOSE
