Audi S6 C6 (2006-2008) suppression strut valves Wiring diagram
This page shows the only wiring diagram for the component.suppression strut valves, which is found in the car Audi S6 C6 (2006-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram suppression strut valves (1 of 1)
4-POSITION RELAY & FUSE PANEL (IN RIGHT PLENUM CHAMBER E-BOX)
ACCUMULATOR VALVES
BLK/GRN WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
COMPRESSOR MOTOR
GRN/BLU WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES SELF-LEVELING SYSTEM FUSE FUSE 110
LEFT FRONT BODY ACCELERATION SENSOR
LEVEL CONTROL PRESSURE SENSOR
LEVEL CONTROL SYSTEM ASSEMBLY
LEVEL CONTROL SYSTEM COMPRESSOR RELAY
LEVEL CONTROL SYSTEM CONTROL MODULE
PUMP TEMPERATURE SENSOR
REAR BODY ACCELERATION SENSOR
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RIGHT FRONT BODY ACCELERATION SENSOR
SOLENOID
SUPPRESSION STRUT VALVES
VALVE BODY
WHT WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
Go to component: -> Electronic suspension circuit (2 of 2) -> SUPPRESSION STRUT VALVES
