Audi S6 C6 (2006-2008) state solid wiring diagram
This page shows the only wiring diagram for the component.state solid, which is found in the car Audi S6 C6 (2006-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
state solid wiring diagram (1 of 1)
AIRBAG CONTROL MODULE (BELOW CENTER OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/YEL WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
DRIVER'S FRONT AIRBAG CRASH SENSOR
GRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY WIRE
LEFT SAFETY BELT SWITCH
ORG/BLK WIRE
ORG/BRN WIRE
PASSENGER'S FRONT AIRBAG CRASH SENSOR
RED WIRE
RIGHT SAFETY BELT SWITCH AND SEAT OCCUPIED RECOGNITION SAFETY BELT FORCE SENSOR
SIDE AIR BAG CRASH SENSOR (RIGHT REAR) (AT BOTTOM OF RIGHT "C" PILLAR)
SIDE AIR- BAG CRASH SENSOR (LEFT REAR) (AT BOTTOM OF LEFT "C" PILLAR)
SIDE AIRBAG CRASH SENSOR (DRIVER'S SIDE) (IN DRIVER'S DOOR)
SIDE AIRBAG CRASH SENSOR (FRONT PASSENGER'S SIDE) (IN FRONT PASSENGER'S DOOR)
SOLID
SOLID STATE
STATE
STATE SOLID
VIO WIRE
VIO/BLU WIRE
WARNING LIGHT FOR AIRBAG OFF (PASSENGER'S SIDE)
WHT WIRE
YEL WIRE
YEL/BRN WIRE
Go to component -> Supplemental restraints circuit (3 of 3) -> STATE SOLID
