Audi S6 C6 (2006-2008) right rear parking aid sensor Wiring diagram

This page shows the only wiring diagram for the component.right rear parking aid sensor, which is found in the car Audi S6 C6 (2006-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram right rear parking aid sensor (1 of 1)

Wiring diagram right rear parking aid sensor for Audi S6 C6 (2006-2008)

Get access

BLK WIRE BLK/RED WIRE BLU/RED WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM FUSE FUSE 11 FUSE 7 GRN WIRE HOT AT ALL TIMES HOT W/ POWER SUPPLY RELAY ENERGIZED LEFT REAR CENTER PARKING AID SENSOR LEFT REAR PARKING AID SENSOR ORG/BRN WIRE ORG/GRN WIRE PARKING AID CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT) REAR PARKING AID WARNING BUZZER RED WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT REAR CENTER PARKING AID SENSOR RIGHT REAR PARKING AID SENSOR YEL/BRN WIRE YEL/RED WIRE

Go to component: -> Parking assistant circuit -> RIGHT REAR PARKING AID SENSOR
