Audi S6 C6 (2006-2008) right rear door central locking lock unit Wiring diagram

This page shows the only wiring diagram for the component.right rear door central locking lock unit, which is found in the car Audi S6 C6 (2006-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram right rear door central locking lock unit (1 of 1)

Wiring diagram right rear door central locking lock unit for Audi S6 C6 (2006-2008)

Get access

BLK WIRE BLU WIRE BLU/GRN WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DOOR LOCKS SYSTEM FRONT PASSENGER'S DOOR CENTRAL LOCKING LOCK UNIT FRONT PASSENGER'S DOOR CONTROL MODULE (IN RIGHT FRONT DOOR) FUSE FUSE 10 FUSE 6 GRY/YEL WIRE HOT AT ALL TIMES ORG/BRN WIRE ORG/GRN WIRE RED/BLU WIRE RED/YEL WIRE RIGHT REAR DOOR CENTRAL LOCKING LOCK UNIT RIGHT REAR DOOR CONTROL MODULE (IN RIGHT REAR DOOR) TRUNK LOCK ALARM/CENTRAL LOCKING SWITCH WHT/BLU WIRE WHT/YEL WIRE

Go to component: -> Anti-theft circuit (2 of 2) -> RIGHT REAR DOOR CENTRAL LOCKING LOCK UNIT
