Audi S6 C6 (2006-2008) passenger's seat height adjustment motor Wiring diagram

This page shows the only wiring diagram for the component.passenger's seat height adjustment motor, which is found in the car Audi S6 C6 (2006-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram passenger's seat height adjustment motor (1 of 1)

Wiring diagram passenger's seat height adjustment motor for Audi S6 C6 (2006-2008)

Get access

BACKREST BLK WIRE BLU WIRE BRN WIRE CIRCUIT BREAKER DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH DRIVER SEAT LUMBAR SUPPORT CURVATURE ADJUSTING MOTOR DRIVER SEAT LUMBAR SUPPORT HEIGHT ADJUSTING MOTOR DRIVER'S POWER SEAT ADJUSTMENT DRIVER'S POWER SEAT SWITCH DRIVER'S SEAT BACKREST ADJUSTMENT MOTOR DRIVER'S SEAT FORE/AFT ADJUSTMENT MOTOR DRIVER'S SEAT HEIGHT ADJUSTMENT MOTOR DRIVER'S SEAT INCLINATION ADJUSTMENT MOTOR FORE/AFT HEIGHT HOT AT ALL TIMES PASSENGER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH PASSENGER SEAT LUMBAR SUPPORT CURVATURE ADJUSTING MOTOR PASSENGER SEAT LUMBAR SUPPORT HEIGHT ADJUSTING MOTOR PASSENGER'S POWER SEAT SWITCH PASSENGER'S SEAT BACKREST ADJUSTMENT MOTOR PASSENGER'S SEAT FORE/AFT ADJUSTMENT MOTOR PASSENGER'S SEAT HEIGHT ADJUSTMENT MOTOR PASSENGER'S SEAT INCLINATION ADJUSTMENT MOTOR RED WIRE RED/WHT WIRE TILT WHT WIRE YEL WIRE

Go to component: -> Power seats circuit -> PASSENGER'S SEAT HEIGHT ADJUSTMENT MOTOR
